| Below
are samples of various bar code symbologies. These samples
are intended to provide an idea of the approximate size.
They are not intended to be scannable images.
Interleaved
2 of 5
H=Height,
N=Ratio, X=Narrow Bar Width
|
TOF01P
|
Prop. |
H=0.25" |
N=2.0:1 |
X=7 |
Data:012345 |
|
TOF02P
|
Prop. |
H=0.25" |
N=2.0:1 |
X=6 |
Data:012345 |
|
TOF03P
|
Prop. |
H=0.25" |
N=2.0:1 |
X=8 |
Data:012345 |
|
TOF04P
|
Prop. |
H=0.33" |
N=2.5:1 |
X=6 |
Data:012345 |
|
TOF05P
|
Prop. |
H=0.25" |
N=2.0:1 |
X=9 |
Data:012345 |
|
TOF06P
|
Prop. |
H=0.25" |
N=2.0:1 |
X=11 |
Data:012345 |
|
TOF07P
|
Prop. |
H=0.25" |
N=2.0:1 |
X=5 |
Data:012345 |
|
TOF08P
|
Prop. |
H=0.25" |
N=3.0:1 |
X=6 |
Data:012345 |
|
TOF10P
|
Prop. |
H=0.25" |
N=3.0:1 |
X=3 |
Data:012345 |
|
TOF11P
|
Prop. |
H=0.25" |
N=3.0:1 |
X=9 |
Data:012345 |
|
TOF12P
|
Prop. |
H=0.25" |
N=3.0:1 |
X=7 |
Data:012345 |
|
TOF20P
|
Prop. |
H=0.5" |
N=3.0:1 |
X=3 |
Data:012345 |
|
TOF26P
|
Prop. |
H=0.25" |
N=3.0:1 |
X=4 |
Data:012345 |
|
TOF31P
|
Prop. |
H=0.5" |
N=2.5:1 |
X=6 |
Data:012345 |
